End of life. Jetson TX1 has reached end of life. Jetson Orin Nano is the recommended successor for new designs.
Overview
The NVIDIA Jetson TX1 was the first credit-card-sized Jetson module, combining a 256-core NVIDIA Maxwell GPU delivering over 1 TFLOPS of FP16 compute with a quad-core Arm Cortex-A57 CPU, 4GB of LPDDR4 and 16GB of eMMC in a 400-pin module.
The module is discontinued. It shares its 400-pin connector with Jetson TX2, which is also end of life, so migrations move to the Jetson Orin family on new carriers.
Key Features
- 256-core Maxwell GPU: Over 1 TFLOPS of FP16 compute
- Quad-core Cortex-A57: 64-bit Arm CPU
- 4GB LPDDR4: 25.6 GB/s
- 16GB eMMC: On-module storage
- Under 10W: Typical power for the full module
Technical Specifications
| Specification | Details |
|---|---|
| GPU | 256-core NVIDIA Maxwell GPU |
| CPU | Quad-core Arm Cortex-A57 |
| Memory | 4GB 64-bit LPDDR4, 25.6 GB/s |
| Storage | 16GB eMMC |
| Video Encode | 4K30 (H.264/H.265) |
| Video Decode | 4K60 (H.264/H.265) |
| Camera | 12 lanes MIPI CSI-2 |
| Networking | Gigabit Ethernet, 802.11ac Wi-Fi, Bluetooth |
| Form Factor | 87 mm x 50 mm, 400-pin connector |
| Status | End of life |
Ideal Use Cases
- Reference for legacy TX1 products
- Migration planning to the Jetson Orin family
Why Choose This Product?
This page documents the discontinued Jetson TX1 module for teams that still maintain products built on it.
Looking for a current alternative? Talk to us and we will recommend the right Jetson platform for your migration.
